FLAUTO 2
Ο οίκος IRSAP S.p.a είναι ένας πρωτοποριακός κατασκευαστής στον τομέα θέρμανσης-κλιματισμού στην Ιταλία.
Η αρχική του δραστηριότητα ήταν η παραγωγή σωληνωτών θερμαντικών σωμάτων.
Σήμερα κατέχει περίπου το 80% της ιταλικής αγοράς στα σωληνωτά σώματα και είναι αδιαμφισβήτητα πρωτοπόρος στα θερμαντικά σώματα λουτρού.
Η δυνατότητα παραγωγής του εργοστασίου είναι τριάντα δύο χιλιάδες (32.000) στοιχεία της σειράς TESI ημερησίως και ένα εκατομμύριο διακόσιες χιλιάδες(1.200.000) τεμάχια σωμάτων λουτρού ετησίως.
- Actual Power 0,00 kW
- Produced power 10.972.131,88 kWh
- CO2 emission 5.826,20 t
| Model | Deph (mm) | Height (mm) | Width (mm) | Conn. C. (mm) | Weigth (kg) | Capacity (lt) | COM_PRODUCTS_TABLE_DATA_BTU | Δt=50°C (kcal/h) | Δt=50°C (Watt) | Δt=40°C (Watt) | Δt=30°C (Watt) | Δt=20°C (Watt) | Exponent | mixed oper. (Watt) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 810 40 rails 2 espaces | 62,0 | 810 | 456 | 406 | 9,80 | 4,50 | 1.975,0 | 498,0 | 579,0 | 444,0 | 315,0 | 194,0 | 1,192 | 400 |
| 810 40 rails 2 espaces | 62,0 | 810 | 506 | 456 | 10,70 | 4,90 | 2.192,0 | 552,0 | 642,0 | 492,0 | 349,0 | 215,0 | 1,196 | 400 |
| 810 40 rails 2 espaces | 62,0 | 810 | 556 | 506 | 11,60 | 5,30 | 2.408,0 | 607,0 | 706,0 | 540,0 | 382,0 | 235,0 | 1,199 | 700 |
| 810 40 rails 2 espaces | 62,0 | 810 | 606 | 556 | 12,50 | 5,70 | 2.625,0 | 662,0 | 769,0 | 588,0 | 416,0 | 256,0 | 1,203 | 700 |
| 810 40 rails 2 espaces | 62,0 | 810 | 756 | 706 | 15,30 | 6,90 | 3.275,0 | 826,0 | 960,0 | 732,0 | 516,0 | 316,0 | 1,214 | 1000 |
| 1218 60 rails 3 espaces | 62,0 | 1218 | 456 | 406 | 14,70 | 6,80 | 2.796,0 | 705,0 | 820,0 | 624,0 | 439,0 | 268,0 | 1,221 | 700 |
| 1218 60 rails 3 espaces | 62,0 | 1218 | 506 | 456 | 16,00 | 7,40 | 3.107,0 | 783,0 | 911,0 | 694,0 | 488,0 | 298,0 | 1,221 | 700 |
| 1218 60 rails 3 espaces | 62,0 | 1218 | 556 | 506 | 17,40 | 8,00 | 3.418,0 | 862,0 | 1.002,0 | 763,0 | 537,0 | 328,0 | 1,220 | 1000 |
| 1218 60 rails 3 espaces | 62,0 | 1218 | 606 | 556 | 18,80 | 8,60 | 3.730,0 | 940,0 | 1.093,0 | 833,0 | 586,0 | 358,0 | 1,220 | 1000 |
| 1218 60 rails 3 espaces | 62,0 | 1218 | 756 | 706 | 22,90 | 10,30 | 4.664,0 | 1.175,0 | 1.367,0 | 1.041,0 | 733,0 | 447,0 | 1,219 | 1000 |
| 1558 76 rails 4 espaces | 62,0 | 1558 | 456 | 406 | 18,60 | 8,70 | 3.606,0 | 909,0 | 1.057,0 | 803,0 | 563,0 | 342,0 | 1,232 | 1000 |
| 1558 76 rails 4 espaces | 62,0 | 1558 | 506 | 456 | 20,30 | 9,40 | 3.985,0 | 1.004,0 | 1.168,0 | 889,0 | 625,0 | 381,0 | 1,223 | 1000 |
| 1558 76 rails 4 espaces | 62,0 | 1558 | 556 | 506 | 22,10 | 10,10 | 4.364,0 | 1.100,0 | 1.279,0 | 975,0 | 688,0 | 420,0 | 1,215 | 1000 |
| 1558 76 rails 4 espaces | 62,0 | 1558 | 606 | 556 | 23,80 | 10,90 | 4.743,0 | 1.195,0 | 1.390,0 | 1.062,0 | 751,0 | 460,0 | 1,206 | 1000 |
| 1558 76 rails 4 espaces | 62,0 | 1558 | 756 | 706 | 29,00 | 13,10 | 5.879,0 | 1.482,0 | 1.723,0 | 1.324,0 | 942,0 | 584,0 | 1,181 | 1000 |
| 1762 88 rails 4 espaces | 62,0 | 1762 | 456 | 406 | 21,40 | 10,00 | 4.107,0 | 1.035,0 | 1.204,0 | 912,0 | 638,0 | 386,0 | 1,242 | 1000 |
| 1762 88 rails 4 espaces | 62,0 | 1762 | 506 | 456 | 23,40 | 10,80 | 4.584,0 | 1.155,0 | 1.343,0 | 1.021,0 | 717,0 | 435,0 | 1,230 | 1000 |
| 1762 88 rails 4 espaces | 62,0 | 1762 | 556 | 506 | 25,50 | 11,70 | 5.061,0 | 1.276,0 | 1.483,0 | 1.130,0 | 796,0 | 486,0 | 1,219 | 1000 |
| 1762 88 rails 4 espaces | 62,0 | 1762 | 606 | 556 | 27,50 | 12,60 | 5.537,0 | 1.396,0 | 1.623,0 | 1.240,0 | 876,0 | 537,0 | 1,207 | 1000 |
| 1762 88 rails 4 espaces | 62,0 | 1762 | 756 | 706 | 33,50 | 15,10 | 6.968,0 | 1.756,0 | 2.042,0 | 1.572,0 | 1.122,0 | 697,0 | 1,173 | 1000 |
